TOP-FLO® Ball Valves are engineered to be the finest in the industry. Each valve is built to exact specifications and is constructed to perform flawlessly in the most hostile environment. TOP-FLO® Ball Valves are utilized by firms that demand the uncompromised ability to regulate flow – from full flow open to various degrees of closure.
TOP-FLO® SERIES TF4 - DIRECT MOUNT
| Part Number | Size (inches) | Pressure Rating @ 170°F. | End Connection | A | B | C | ISO-5211 | STP File |
|---|---|---|---|---|---|---|---|---|
| 384305TEF4 | 1/2 | 1,000 PSI | Clamp | 3.50 | 2.78 | .354 (9mm) | F04 F05 | |
| 384307TEF4 | 3/4 | 1,000 PSI | Clamp | 3.98 | 2.91 | .354 (9mm) | F04 F05 | STP |
| 384310TEF4 | 1 | 1,000 PSI | Clamp | 4.49 | 3.36 | .433 (11mm) | F04 F05 | STP |
| 384315TEF4 | 1-1/2 | 1,000 PSI | Clamp | 5.51 | 3.92 | .551 (14mm) | F05 F07 | STP |
| 384320TEF4 | 2 | 1,000 PSI | Clamp | 6.14 | 4.24 | .551 (14mm) | F05 F07 | STP |
| 384325TEF4 | 2-1/2 | 800 PSI | Clamp | 7.76 | 5.74 | .669 (17mm) | F07 F10 | STP |
| 384330TEF4 | 3 | 800 PSI | Clamp | 9.02 | 6.09 | .669 (17mm) | F07 F10 | STP |
| 384340TEF4 | 4 | 800 PSI | Clamp | 9.48 | 7.40 | .866 (22mm) | F10 | STP |
| 384360TEF4 | 6 | 250 PSI | Clamp | N/A | N/A | N/A | N/A |
Features:
- 360° Installation – Valve may be installed in any position.
- Sizes – 1/2″ -6″
- Materials – 316 SS
- PTFE cavity fillers are precision machined to maintain a sanitary environment.
- Easy “In-line” servicing. Unique design allows valve ends to remain attached while servicing valve body.
- No special tools needed.
- Minimal turbulence – maximum flow through.
- USDA approved
- ISO 5211 Mounting Pad
- Surface finish ID: 20Ra
Steel & O’Brien offers several different types of switch packages and control monitors for position feedback to PLC.
Optional integrally mounted or externally mounted solenoid valves are also available.
Options include….
Point-to-Point:
- Mechanical
- Proximity
- Namur
Network Type:
- AS-i
- DeviceNet
- Foundation Fieldbus
- Modbus
Manufactures available but not limited to Westlock, StoneL, Moniteur, Burkert, A-T Controls
Note: Not all platforms are available on all valve types. Consult the factory for availability depending on requirements.
